In 1981, the second- and fourth-story suspended balconies in the Hyatt Regency Hotel in Kansas City collapsed and killed 114 people and injured 200 others. Investigation determined that the catastrophe resulted from a seemingly simple, but fatally flawed, field change that did not get the analysis it needed.
I’ve done many exercises showing the proposed change to people in technical fields and without referring to the catastrophe, asking them if they felt that the change would affect the integrity of the design. Most generally believe that the change would have no effect on the loading of the walkways. Similarly, I’ve shown that same change to freshman-level students, but direct them to take two or three minutes to draw it out, label the forces, and run the numbers before answering. Almost without exception, freshmen in an introductory-level statics class can easily see the huge effect of the proposed change. The design change was apparently accepted by experts in the field but was not accompanied by a simple analysis of the forces, and that shortcut cost 114 innocent victims their lives in one of the most catastrophic engineering failures in recent history. A simple freshman-level analysis could have averted the problem entirely.
Something happens when we leave the classroom and move into the field. We face a very different environment from where we learned the fundamental theory, whether in the university or a professional training seminar. Maybe we abandon the analysis because the real world is loud and dirty, fast-moving, and seemingly very different than the “textbook” environment we were schooled in. Maybe it’s because it’s so demanding and we don’t feel we have the time. There are no “givens” printed out in neat order with an accompanying diagram. When we begin work in a plant environment, we are immediately surrounded by people with tremendously more experience than we have ourselves; they seem to have accepted ways to work that don’t include a lot of book-work, and we begin to rely on intuition, rules of thumb, and accepted experts in the field.
There is nothing wrong with seeking opinions and guidance from those around us. It is also fine for us to use our own judgment and common sense. The problem occurs when we simultaneously abandon all education that came before, or when we stop taking the time to re-visit the basic principles, and yes, actually run the numbers.
The human mind can be very effective in making good judgments and drawing good conclusions based on intuition or common sense. Remember though, that the human mind does not process parameters that are not linear very well at all. A person estimating the total interest paid on a 30-year mortgage rarely gets close because compound interest is exponential rather than linear. The holder of a lottery ticket often has a completely unreasonable sense of hope because probability factorials are certainly not linear.
For phenomena that are non-linear, we think our intuition is much better than it really is. Are our piping systems linear? Substituting a 2-inch line for a 4-inch line doesn’t double the velocity, it quadruples it. Quadrupling velocity with a given friction factor doesn’t quadruple the energy loss, it increases it by a factor of 16. Increasing energy losses in a suction line doesn’t linearly degrade a pump, but rather it sets into place many other non-linear results that drive bearing load (a squared relationship), bearing life (cubic), and cavitation ( a suddenly crossed threshold). Fluid systems are non-linear and our judgment and intuition is not nearly as good as we think it is. We must “run the numbers” to make good decisions.
Consider three quick samples that might arise in your facility:
1. A system with a horizontal run is designed with 1.5-inch steel pipe to carry 90 GPM of water. Due to a minor oversight, it was installed with 1-inch line. Since the line is difficult to see and the OD is 1.3 inches anyway, the change has gone unnoticed since installation. The decision is made to leave the line in place given the difficulty of pulling and reinstalling what is nearly the same size pipe anyway.
Result determined by running the numbers: The head on the pump goes from a designed value of about 50 feet to over 200 feet with the smaller pipe! At the same time, the pressure drop across the line goes from about 20 PSI to over 90 PSI. The effect on the pump is significant, but even if a different pump is installed to match this system, power consumption increases by 2.7 kW, more than a factor of four, the entire time this system is operated.
2. A pump is installed next to a column, and a look at the original drawing indicates that the column was not accounted for during the design process. What was to be a short-straight suction line from the tank became a series of four elbows going around the column, but the system seems to work now and there really is no easy way around stationary columns.
Result determined by running the numbers: The designed suction line had less than a foot of head loss, and it was replaced with one that introduces losses of over three feet! This difference takes the application from a robust design to one that lacks adequate net positive suction head available over some of its operating range, resulting in cavitation, in addition to any effects that result from an inadequate straight run to the pump.
3. An application runs in two different modes, one at 600 GPM and one at 300 GPM. You notice that a pullout pump is in place, but the impeller is never changed. Your research indicates that initially changes were made between seasons, swapping the 10-inch impeller for a 7-inch.
Maintenance and production met at some point, however, and determined that the time to make the change, both in labor and lost time, are simply not worth it. The larger impeller works for both settings. The change is rather minor anyway and the smaller flow can be achieved with an easy valve adjustment.
